5. Chrominance & Luminance
No. Item Min Typ Max Unit Remarks
1 Max Luminance 320 400 cd/m
2
32/42LK430-UA
(Center 1-point / Full White Pattern)
2 Luminance uniformity
3 Color coordinate RED X Typ. 0.64 Typ. 32LK430-UA
(Default) Y -0.03 0.33 +0.03
GREEN X 0.29
Y 0.60
BLUE X 0.15
Y 0.06
WHITE X 0.28
Y 0.29
RED X Typ. 0.636 Typ. 42LK430-UA
Y -0.03 0.335 +0.03
GREEN X 0.291
Y 0.603
BLUE X 0.146
Y 0.061
WHITE X 0.279
Y 0.292
4 Contrast ratio Module 3200 4000 32/42LK430(AUO)
DCR 90,000:1 100,000:1 32LK430(AUO)
30,000:1 40,000:1 32/42LK430(AUO)
5 Color Temperature Cool 0.254 0.269 0.284
13000K The W/B Tolerance is ±0.015
0.258 0.273 0.288 for picture quality by DQA
Medium 0.270 0.285 0.300 9300K
0.278 0.293 0.308
Warm 0.298 0.313 0.324
6500K
0.314 0.329 0.344
