LG 32LN549C Service Manual

- 6 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the LED TV used LB3AC
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC : CE, IEC
4. Model General Specification
No. Item Specication Remarks
1 Market
Asia, Oceania, Africa, Middle East
(PAL/DVB Market)
Only Analog for A-ASIA
2. Broadcasting system
1) PAL/SECAM-B/G/D/K
2) PAL-I
3) NTSC-M
4) DVB-T
PAL
3 Channel Storage ATV - 135 EA, DTV - 1000 EA
4 Receiving system
Analog : Upper Heterodyne
Digital : COFDM(DVB-T)
► DVB-T
- Guard Interval(Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32
- Modulation : Code Rate
QPSK : 1/2, 2/3, 3/4, 5/6, 7/8
16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
5 Video(Composite) Input PAL, SECAM, NTSC 4 System : PAL, SECAM, NTSC, PAL60
6 RGB Input(1EA) RGB-PC Analog(D-SUB 15PIN)
7 Component Input Y/Cb/Cr, Y/Pb/Pr Spec out
8 HDMI Input
HDMI1-DTV/DVI
HDMI2-DTV/DV
HDMI3-DTV/DVI
Common Port in AV & PC input.
9 Audio Input (1EA)
RGB/DVI Audio
AV
10 SDPIF out SPDIF out
11 USB For My Media(Movie/Photo/Music List) and SVC
12 External Speaker Max 1W @ 8 ohm Stereo SE output

LG 32LN549C Specifications

General

Smart modes	Hotel
Screen shape	Flat
Response time	9 ms
Display diagonal	32 \
Display brightness	300 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Display diagonal (metric)	81 cm
3D	No
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-T
Audio system	Infinite Sound
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Common interface Plus (CI+)	-
Product color	Black
Cable lock slot type	Kensington
Panel mounting interface	200 x 100 mm
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	64 W
Sustainability certificates	RoHS

Weight and Dimensions

Depth (with stand)	207 mm
Height (with stand)	497 mm
Depth (without stand)	79 mm
Width (without stand)	738 mm
Weight (without stand)	7000 g
