5.2. HDMI Input(PC/DTV)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
DTV
1 720*480 31.469 / 31.5 59.94 / 60 27.00/27.03 SDTV 480P
2 720*576 31.25 50 54 SDTV 576P
3 1280*720 37.500 50 74.25 HDTV 720P
4 1280*720 44.96 / 45 59.94 / 60 74.17/74.25 HDTV 720P
5 1920*1080 33.72 / 33.75 59.94 / 60 74.17/74.25 HDTV 1080I
6 1920*1080 28.125 50.00 74.25 HDTV 1080I
7 1920*1080 26.97 / 27 23.97 / 24 74.17/74.25 HDTV 1080P
8 1920*1080 33.716/33.75 29.976/30.00 74.25 HDTV 1080P
9 1920*1080 56.250 50 148.5 HDTV 1080P
10 1920*1080 67.43 / 67.5 59.94 / 60 148.35/148.50 HDTV 1080P
PC
1 640*350 @70Hz 31.468 70.09 25.17 EGA
2 720*400 @70Hz 31.469 70.08 28.321 DOS
3 640*480 @60Hz 31.469 59.940 25.175 VESA(VGA)
4 800*600 @60Hz 37.879 60.31 40.000 VESA(SVGA)
5 1024*768 @60Hz 48.363 60.00 65.000 VESA(XGA)
6 1152*864 @60Hz 54.348 60.053 80.002 VESA
7 1280*1024 @60Hz 63.981 60.020 108 VESA(SXGA)
FHD only(Support
to HDMI-PC)
8 1360*768 @60Hz 47.712 60.015 85.5 VESA(WXGA)
9 1920*1080 @60Hz 67.5 60.0 148.5
WUXGA
(Reduced blanking)
FHD only(Support
to HDMI-PC)

LG 32LN549C Specifications

General

Smart modes	Hotel
Screen shape	Flat
Response time	9 ms
Display diagonal	32 \
Display brightness	300 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Display diagonal (metric)	81 cm
3D	No
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-T
Audio system	Infinite Sound
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Common interface Plus (CI+)	-
Product color	Black
Cable lock slot type	Kensington
Panel mounting interface	200 x 100 mm
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	64 W
Sustainability certificates	RoHS

Weight and Dimensions

Depth (with stand)	207 mm
Height (with stand)	497 mm
Depth (without stand)	79 mm
Width (without stand)	738 mm
Weight (without stand)	7000 g
