STAND INSTRUCTIONS
(For 26/32/37/42/47/55LE5300, 32/42/47/55LE4600)
ꔛ
Image shown may differ from your TV.
INSTALLATION
NOTE
► When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3
Assemble the TV as shown.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
4
Assemble the part of the STAND
REAR COVER with the TV.
5
Install the 4 screws into the holes shown.
STAND BASE
STAND BODY
STAND REAR
COVER
M4 x 22 M4 x 24 M4 x 26M4 x 20
M4 x 16M4 x 14
For 26LE5300
26LE5300
Other models
32LE5300,
32/42/47/55LE4600
37/42LE5300 47/55LE5300
