No. Item Specication Remarks
2 Broadcasting system
Analogue TV
1) PAL-BG
2) PAL-DK
3) PAL-I/I’
4) SECAM L/L’
Digital TV
1) DVB-T/C/T2
Satellite Digital TV
1) DVB-T/C/S/S2
Analogue TV : (RF) VHF: E2 to E12, UHF : E21 to E69
(CATV) S1 to S20, HYPER: S21 to S47
Digital TV : VHF, UHF
Satellite TV : VHF, UHF, C-Band, Ku-Band
* DVB-T2 ( T2 model only support )
* DVB-S/S2 (Satellite model only support )
3 Receiving system
Analog : Upper Heterodyne
Digital : COFDM , QAM
► DVB-T
- Guard Interval (Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32
- Modulation : Code Rate
QPSK : 1/2, 2/3, 3/4, 5/6, 7/8
16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
► DVB-T2
- Guard Interval (Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256,
- Modulation : Code Rate
QPSK : 1/2, 2/5, 2/3, 3/4, 5/6
16-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
64-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
256-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
► DVB-C
- Symbolrate :
4.0Msymbols/s to 7.2Msymbols/s
- Modulation :
16QAM, 64-QAM, 128-QAM and 256-QAM
► DVB-S
- symbol rate
DVB-S2 (8PSK / QPSK) : 2 ~ 45Msymbol/s
DVB-S (QPSK) : 2 ~ 45Msymbol/s
- viterbi
DVB-S mode : 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2 mode : 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10
4 Scart Jack (1EA) PAL, SECAM Scart 1 Jack is Full scart and support RF-OUT(analog).
5 Component Input (1EA)
Y/Cb/Cr
Y/Pb/Pr
Phone Jack type
Video only(Rear)
6 RGB Input RGB-PC
Analog(D-SUB 15PIN)
*LN549E-ZA model only support
7 HDMI Input (3EA)
HDMI1-DTV/DVI
HDMI2-DTV
HDMI3-DTV
PC(HDMI version 1.3)
Support HDCP
The number of Input ports is different by model.
8 Audio Input (1EA) RGB/DVI/Component Audio
RGB/DVI & Component Audio common port
* Component/DVI Audio (LP63xH-ZA model support)
* Component/RGB/DVI Audio (LN549E-ZA model support)
9 SDPIF out (1EA) SPDIF out
10 External Speaker out (1EA) Stereo, 1W (8 Ω), Single-End 3P Phone Jack type
11 External Speaker out Control (1EA) Phone Jack 3P Phone Jack type
12 Earphone out (1EA)
Antenna, AV1, AV2, Component,
RGB, HDMI1, HDMI2, HDMI3
13 USB
EMF,
DivX HD,
For SVC (download)
JPEG, MP3, DivX HD
* 1EA (LP63xH-ZA model support )
* 2EA (LN549E-ZA model support )- USB IN, Wireless Dongle
: Wireless Dongle port only use for Wireless
14 DVB
DVB-T
CI : UK, Finland, Denmark, Norway, Sweden, Russia, Spain, Ireland,
Luxemburg, Belgium, Netherland
CI+ : France(Canal+), Italy(DGTVi)
DVB-C
CI : Switzerland, Austria, Slovenia, Hungary, Bulgaria
CI+ : Switzerland(UPC,Cablecom), Netherland(Ziggo),
Germany(KDG,CWB), Finland(labwise)
15 RS232C(1EA) Interactive mode support
16 Ethernet (1EA)
Support only communication with Pro :Centrc Server
Support only LP63xH-ZA model
