LG 42LB5800-UG Service Manual

D. Function error_ No response in remote controller,
k
Established
Error
t
2014 1 6
Standard Repair Process Detail Technical Manual
P4102
Remote controller operation checking method
k
ey erro
r
<ALL MODELS>
A27
date
Revised
date
symp
t
om
Content
LCD TV
2014
.
1
.
6
P4102
1
GND
2
KEY1
3
KEY2
4
+3.5V_ST
③
5
GND
6
LOGO/LED_R
7IR
8GND
9
EYE SCL
④
9
EYE
_
SCL
10 EYE_SDA
Checkin
g
order
①
②
g
1, 2. Check IR cable condition between IR & Main board.
3. Check the st-by 3.5V on the terminal 6.
4. When checking the Pre-Amp when the power is in ON condition, it is normal when the Analog
Tester needle moves slowly, and defective when it does not move at all.
30 / 97
Copyright ⓒ 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
