33
ENGENGLISH
MAKING CONNECTIONS
Headphone connection
Transmits the headphone signal from the TV to
an external device. Connect the external device
and the TV with the headphone as shown.
(*Not Provided)
NOTE
y
AUDIO menu items are disabled when
connecting a headphone.
y
Optical Digital Audio Out is not available
when connecting a headphone.
y
Headphone impedance: 16 Ω
y
Max audio output of headphone: 0.624
mW to 1.04 mW
y
Headphone jack size: 0.35 cm
Satellite dish connection
(Only satellite models)
Connect the TV to a satellite dish to a satellite
socket with a satellite RF cable (75 Ω).
LNB
Satellite IN
13/18V
700mA Max
(*Not Provided)
To Next Page
