LG 42LD452C User Manual

PREPARATION
PREPARATION
24
STAND INSTRUCTIONS
(For 32/37/42/47LD450, 37/42/47LD450C, 42/47/55LD630, 42/47LD451C, 32/27/42/47LD452C)
󰮌
Image shown may differ from your TV.
!
?
!
?
NOTE
► When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
3
Assemble the TV as shown.
4
Install the 4 screws into the holes shown.
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
INSTALLATION
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
M4X20
M4X20
STAND BASE
STAND BODY
M4 x 20
M4 x 20

LG 42LD452C Specifications

General

Brand	LG
Model	42LD452C
Category	LCD TV
Language	English
