SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied to the LED TV used LJ50H chassis
2. Test condition
Each part is tested as below without special notice.
1) Temperature : 25 ºC ± 5 ºC(77±9ºF), CST : 40 ºC±5 ºC
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
Standard input voltage (100~240V@ 50/60Hz)
* Standard Voltage of each products is marked by models.
* Taiwan : 110V 60Hz
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 20 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC: CE, IEC
4. Model Specification
No Item Specication Remark
1. Market Brazil
2. Broadcasting system Digital : SBTVD /
Analog : NTSC / PAL-M / PAL-N
3. Available Channel BAND NTSC
VHF
UHF
DTV
CATV
2 ~ 13
14 ~ 69
2 ~ 69
1 ~ 135
4. Receiving system Digital : SBTVD /
Analog : NTSC / PAL-M / PAL-N
5. Video Input NTSC-M Rear 1EA (Common AV/Component)
6. Component Input Y/Cb/Cr, Y/ Pb/Pr Rear 1EA
7. RGB Input RGB-PC, Spec out
8. HDMI Input PC(HDMI version 1.3) / DTV format, Support
HDCP
Side 2EA
Support ARC only HDMI1
NOT Support MHL
9. Audio Input Component / AV Audio / DVI Audio, Rear 1EA(Common Component / AV / DVI)
10 SPDIF out(1EA) Optical Audio out Rear (1EA)
11 USB Input(2EA) EMF, DivX HD, For SVC (download) Side 2EA
JPEG, MP3, DivX HD
