5.2. HDMI : EDID DATA : Refer to adjust specification

5.2.1. DTV mode

No Resolution H-freq(kHz) V-freq.(Hz) Proposed Remark

1 640 x 480 31.46 59.94 SDTV 480P

2 640 x 480 31.5 60.00 SDTV 480P

3 720 x 480 15.73 59.94 SDTV 480I Comment Only Spec. Sheet

(Spec Out)

4 720 x 480 15.75 60.00 SDTV 480I

5 720 x 576 15.62 50.00 SDTV 576I(DVB)

6 720 x 480 31.47 59.94 SDTV 480P

7 720 x 480 31.5 60.00 SDTV 480P

8 720 x 576 31.25 50.00 SDTV 576P(DVB)

9 1280 x 720 44.96 59.94 HDTV 720P

10 1280 x 720 45 60.00 HDTV 720P

11 1280 x 720 37.5 50.00 HDTV 720P(DVB)

12 1920 x 1080 28.12 50.00 HDTV 1080I(DVB)

13 1920 x 1080 33.72 59.94 HDTV 1080I

14 1920 x 1080 33.75 60.00 HDTV 1080I

15 1920 x 1080 26.97 23.97 HDTV 1080P

16 1920 x 1080 27.00 24.00 HDTV 1080P

17 1920 x 1080 33.71 29.97 HDTV 1080P

18 1920 x 1080 33.75 30.00 HDTV 1080P

19 1920 x 1080 56.25 50.00 HDTV 1080P(DVB)

20 1920 x 1080 67.43 59.94 HDTV 1080P

21 1920 x 1080 67.5 60.00 HDTV 1080P

5.2.2. PC mode

No. Resolution H-freq(kHz) V-freq.(kHz) Proposed Remarks

1 640 x 350 @70Hz 31.46 70.09 EGA

2 720 x 400 @70Hz 31.46 70.08 DOS

3 640 x 480 @60Hz 31.46 59.94 VESA(VGA)

4 800 x 600 @60Hz 37.87 60.31 VESA(SVGA)

5 1024 x 768 @60Hz 48.36 60.00 VESA(XGA)

6 1152 x 864 @60Hz 54.34 60.05 VESA

7 1280 x 1024 @60Hz 63.98 60.02 VESA(SXGA) FHD only

8 1360 x 768 @60Hz 47.71 60.01 VESA(WXGA)

9 1920 x 1080 @60Hz 67.5 60.00 WUXGA(CEA 861D) FHD only
