July 2009 LCD DV 42LH40
2
OUTLINE
OUTLINE
• Main Board
Circuit Board Operation, Troubleshooting of :
• Switch mode Power Supply/Ballast Combination
Section 1
Section 2
Contact Information, Preliminary Matters, Specifications,
LCD Overview, General Troubleshooting Steps,
Signal Distribution, Disassembly Instructions and Voltages
• Ft Control Board
• Side Keys
