July 2009 LCD DV 42LH40
20
Circuit Board Layout
Circuit Board Layout
POWER SUPPLY
LVDS Cable
Ft IR/LED Control
AC
Input
RF
Input
Speaker R
Rear
Inputs
Master
Power
Switch
Side Keys
Speaker L
Backlight
Connections
No T-CON or Ballast board
LVDS Cable
Main PWB
