LG 42LM640S Service Manual

- 9 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
7. HDMI Input
7.1. DTV mode
No. Resolution H-freq(kHz) V-freq.(kHz) Proposed
1. 640*480 31.469 / 31.5 59.94/60 SDTV 480P
2. 720*480 31.469 / 31.5 59.94 / 60 SDTV 480P
3. 720*576 31.25 50 SDTV 576P
4. 720*576 15.625 50 SDTV 576I
5. 1280*720 37.500 50 HDTV 720P
6. 1280*720 44.96 / 45 59.94 / 60 HDTV 720P
7. 1920*1080 33.72 / 33.75 59.94 / 60 HDTV 1080I
8. 1920*1080 28.125 50.00 HDTV 1080I
9. 1920*1080 26.97 / 27 23.97 / 24 HDTV 1080P
10. 1920*1080 25 HDTV 1080P
11. 1920*1080 33.716 / 33.75 29.976 / 30.00 HDTV 1080P
12. 1920*1080 56.250 50 HDTV 1080P
13. 1920*1080 67.43 / 67.5 59.94 / 60 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(Hz) Proposed
1 640 x 350 @70Hz 31.468 70.09 EGA
2 720 x 400 @70Hz 31.469 70.08 DOS
3 640 x 480 @60Hz 31.469 59.94 VESA(VGA)
4 800 x 600 @60Hz 37.879 60.31 VESA(SVGA)
5 1024 x 768 @60Hz 48.363 60.00 VESA(XGA)
6 1152 x 864 @60Hz 54.348 60.053 VESA
7 1280 x 1024 @60Hz 63.981 60.020 VESA(SXGA)
8 1360 x 768 @60Hz 47.712 60.015 VESA(WXGA)
9 1920 x 1080 @60Hz 67.5 60.00 WUXGA(Reduced Blanking))
7.2. PC mode

LG 42LM640S Specifications

General

3D	Yes
Annual energy consumption	76 kWh
Storage temperature (T-T)	-20 - 60 °C
Supported 3D technologies	LG Cinema 3D
Storage relative humidity (H-H)	0 - 85 %
Operating relative humidity (H-H)	0 - 80 %
Display diagonal	42 \
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Display diagonal (metric)	107 cm
Screen format adjustments	4:3, 14:9
Tuner type	Analog & digital
Supported TV bands	CATV, Hyperband, UHF, VHF
Analog signal format system	PAL, SECAM
Digital signal format system	DMB-T, DVB-C, DVB-S
RMS rated power	20 W
Number of speakers	2
DVI port	No
HDMI version	1.4
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	-
USB 2.0 ports quantity	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AC3, MP3, PCM
Image formats supported	JPEG XR
Video formats supported	DIVX, H.264, MKV, MPEG, MPG
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth (with stand)	263 mm
Height (with stand)	644.9 mm
Depth (without stand)	35.2 mm
Width (without stand)	964 mm
Height (without stand)	577.7 mm
Weight (without stand)	12100 g
