144
ENG
ENGLISH
SPECIFICATIONS
Wireless LAN for Broadband/DLNA Adaptor module(WN8522D1) specification
This device only works with compatible LG LED LCD TV. (Only 47/55LW95
**
)
Standard
IEEE802.11a/b/g/n
IEEE802.11a/b/g for Russia
Frequency
Range
2402 to 2483 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Modulation CCK / OFDM / MIMO
Output Power
(Typical)
802.11a: 14 dBm
802.11b: 17 dBm
802.11g: 14 dBm
802.11n: 13 dBm
Data rate
802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 300 Mbps
Antenna Gain
(Typical)
2402 to 2483 MHz: 1.17 dBi
5150 to 5250 MHz: 4.67 dBi
5725 to 5850 MHz: 3.30 dBi
Occupied
bandwidth
802.11a/b/g: HT20
802.11n: HT20/40
RF module(BM-LDS201) specification
(
Only 42/47/55LV77
**
, 42/47/55LW75
**
, 42/47/55LW77
**
, 47/55LW95
**
, 72LZ97
**
)
y Because band channel used by the country could be different, the user can not change or adjust the
operating frequency and this product is set for the regional frequency table.
y FCC ID of Wireless LAN for Broadband/DLNA Adaptor module inside TV
FCC ID : BEJWN8522D1
For TV by using a 2.4 GHz bandwidth radio frequency (RF).
y Output: 1 dBm or lower
y Maximum Communication Distance: 10 m in an open space
y Bandwidth: 2.4 GHz (2.4035 GHz to 2.4783 GHz)
y Transfer Rate: 250 kbps
y FCC ID of RF module inside TV
FCC ID : BEJLDS201
