Plasma Fall 2008 42PG20
Y SUSTAIN ADJUSTMENT DETAILS
(Vs, Va, VSC, VSC, -Vy and Z-Bias Must have already been completed).
Observe the
Picture while
making these
adjustments.
Normally, they do
not have to be
done.
V
V
-
-
Set Up (RAMP) and V
Set Up (RAMP) and V
-
-
Set Down Adjustments
Set Down Adjustments
Y-Drive PWB Test
Point
