LG 42VS20 - User Manual

Other manuals for LG 42VS20

Easy Setup Guide4 pages

User Manual83 pages

Questions and Answers

S
Shawn HolderSep 13, 2025
What to do if no image is displayed on my LG Digital Signage?
- C
  christopher83Sep 13, 2025
  If your LG Digital Signage is not displaying an image, ensure the power cord is properly connected to the outlet and that the power switch is turned on. Adjust the brightness and contrast. If the product is in power saving mode, move the mouse or press any key. Turn both devices off and then back on. Also, check the signal cable and press the 'INPUT' menu on the remote control to check the input signal. If the signal from the PC (video card) is out of the vertical or horizontal frequency range of the product, adjust the frequency range by referring to the Specifications in this manual. Maximum resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI : 1920 x 1080 @ 60 Hz. If the issue persists, the backlight may need repair.
R
Richard WrightAug 25, 2025
How to fix the audio function if it does not work on my LG 42VS20 Monitor?
- J
  Jessica TaylorAug 25, 2025
  If the audio function on your LG Monitor isn't working, first check if the audio cable is connected properly. Then, adjust the volume settings and make sure the sound is set appropriately. You can also try selecting the appropriate equalizer sound. Also try adjusting the volume again.
C
christinaparksAug 25, 2025
What to do if my LG 42VS20 displays 'Check signal cable'?
- R
  Robert VelazquezAug 26, 2025
  If your LG Monitor displays a 'Check signal cable' message, it indicates that the signal cable between your PC and the monitor is not properly connected. You should check the signal cable to ensure it is securely connected. You can also press the 'INPUT' menu on the remote control to check the input signal.
A
Allen GonzalezSep 23, 2025
How to unlock 'Key Lock On' on LG Monitor?
- A
  Ashley NavarroSep 23, 2025
  If a 'Key Lock On' message appears when you press the Menu button on your LG Monitor, go to Menu, then Option, and disable the Key Lock option to release the lock.
B
Brian CooleySep 13, 2025
Why is the screen color abnormal on my LG Digital Signage?
- W
  williamstylerSep 14, 2025
  If the screen color on your LG Digital Signage appears abnormal, set the number of colors to more than 24 bits (true color) by selecting Control Panel - Display - Settings - Color Table menu in Windows. Also, check the connection status of the signal cable and re-insert the PC video card. Note that several pixels (red, green, white or black color) may appear on the screen, which is attributable to the unique characteristics of the LCD panel and not a malfunction.
S
sfordSep 22, 2025
How to fix abnormal screen image on LG Monitor?
- M
  Mary AdkinsSep 22, 2025
  If the screen image on your LG Monitor looks abnormal, first, press the "AUTO" button on the remote control to automatically select the optimal screen status that fits the current mode. Also, check if the video card resolution and frequency are supported by the product. You may also use the Clock OSD menu or the Phase OSD menu. Ensure that you connect the signal cable that matches with the source input signal.
J
jordanparkerSep 6, 2025
How to fix poor color resolution (16 colors) on LG Monitor?
- D
  Dustin CraigSep 6, 2025
  To fix a poor color resolution (16 colors) issue on your LG Monitor, set the number of colors to more than 24 bits (true color). You can do this by selecting Control Panel - Display - Settings - Color Table menu in Windows.
J
Jean CollinsSep 7, 2025
Why is the screen position wrong on my LG 42VS20 Monitor?
- P
  Patricia BrownSep 7, 2025
  If the screen position is wrong on your LG Monitor when using a D-Sub analog signal, press the "AUTO" button on the remote control to automatically select the optimal screen status. If adjustment is not satisfactory, use the Position OSD menu. Also, check if the video card resolution and frequency are supported by the product. If the frequency is out of range, set to the recommended resolution in the Control Panel "Display" Setting menu.
W
William HarveySep 23, 2025
What to do if after-image appears on LG Monitor?
- M
  Marcus RichardsSep 23, 2025
  If an after-image appears on your LG Monitor, consider using the screen-saver function to help prevent this issue.
Z
zmartinezAug 31, 2025
What to do if the screen image looks abnormal on my LG Monitor?
- S
  Sarah SteinAug 31, 2025
  If the screen image on your LG Monitor looks abnormal, press the "AUTO" button on the remote control to automatically select the optimal screen status. If this doesn't resolve the issue, use the Position, Clock, or Phase OSD menus for fine-tuning. Ensure that the video card resolution and frequency are supported by the monitor; if the frequency is out of range, set the recommended resolution in the Control Panel "Display" settings. Verify you're using the correct signal cable for your source input signal.

Summary

Licenses

Assembling and Preparing

Parts and Buttons

Identifies and describes the monitor's physical buttons and connection ports.

Mounting on a Wall

Details the process and precautions for safely mounting the monitor on a wall.

Remote Control

Remote Control Overview

Details the functions and operation of each button on the remote control.

Using the Monitor Set

Connecting to a PC

Instructions for connecting a personal computer to the monitor for display.

DVI Connection

Explains how to connect a PC using a DVI cable for digital video signal transmission.

Customizing Image Options

Explains how to adjust advanced picture settings like brightness, contrast, and color.

Entertainment

Connecting to a Wired Network

Instructions for connecting the monitor to a local area network via LAN.

Connecting USB Storage Devices

Guides on connecting USB devices like flash drives for multimedia playback.

DivX VOD Guide

Instructions for registering or deregistering the device for DivX® VOD content.

Customizing Settings

Accessing Main Menus

Guides on navigating the monitor's main menu structure and options.

Picture Settings

Covers adjusting image parameters like aspect ratio, brightness, contrast, and picture modes.

Audio Settings

Details how to adjust sound quality, balance, sound modes, and other audio features.

Option Settings

Covers general settings like language, power indicator, ISM method, and factory reset.

Network Settings

Details on configuring network settings, status, and server IP for SuperSign Manager.

Making Connections

Connecting External Devices

HDMI Connection

Details the digital video and audio connection via HDMI cable.

Connecting to the LAN

Connecting to a USB

Troubleshooting

No Image Displayed

Troubleshooting steps for issues with no display or dark screens.

Abnormal Screen Image

Audio Function Not Working

Specifications

LCD Panel Specifications

Video Signal Specifications

IR Codes

IR Code Reference

Lists IR codes, functions, and remote control button mapping for device control.

Controlling the Multiple Product

Connecting Cables

RS-232 C Configurations

Command Reference List

A comprehensive list of commands, their hexadecimal data, and related functions.

Transmission;Receiving Protocol

LG 42VS20 Specifications

General

Resolution	1920 x 1080
Aspect Ratio	16:9
Screen Size	42 inches
Display Type	LED
Native Resolution	1920 x 1080
Brightness	500 nit
Viewing Angle (H x V)	178 x 178
Viewing Angle	178°
Input Connectors	HDMI, Component, Composite, RF
