LG 43LX570M User Manual

21
ENGLISH
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a Cross-over cable or Null Modem cable.
Command Reference List
(Depending upon model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power* k a 00 to 01 15. Balance k t 00 to 64
02. Aspect Ratio k c (page 23)
16. Color
(Colour)
Temperature
x u 00 to 64
03. Screen Mute k d (page 23)
17. ISM Method
(Only Plasma
TV)
j p (page 25)
04. Volume
Mute
k e 00 to 01 18. Equalizer j v (page 25)
05. Volume
Control
k f 00 to 64
19. Energy
Saving
j q 00 to 05
06. Contrast k g 00 to 64
20. Tune
Command
m a (page 25)
07. Brightness k h 00 to 64
21. Channel
(Programme)
Add / Del(Skip)
m b 00 to 01
08. Color / Colour k i 00 to 64 22. Key m c Key Codes
09. Tint k j 00 to 64
23. Control
Backlight,
Control Panel
Light
m g 00 to 64
10. Sharpness k k 00 to 32
24. Input select
(Main)
x b (page 27)
11. OSD Select k l 00 to 01
25. 3D (Only
3D models)
x t (page 27)
12. Remote
Control Lock
Mode
k m 00 to 01
26. Extended
3D (Only 3D
models)
x v (page 28)
13. Treble k r 00 to 64
27. Auto
Configure
j u (page 28)
14. Bass k s 00 to 64
* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not executed
and treated as NG.
With RS232C cable, TV can communicate ka command in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.

LG 43LX570M Specifications

General

Panel life	- h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	43 \
Display brightness	- cd/m²
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1200:1
Display number of colors	-
USB version	2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sound modes	Dynamic, Game, Music, News, Sports, Standard
RMS rated power	10 W
Impedance	8 Ω
Weight (without stand)	9979.03214 g
AC input voltage	110 - 127 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	42 W
Product design	Digital signage flat panel
Panel mounting interface	200 x 200 mm
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574.04 mm
Width	972.82 mm
Height	55.88 mm
