40
Command Data
(Hexadecimal)
1 2
26 Check product serial number f y FF
27 Software Version f z FF
28 White Balance Red Gain j m 00 to FE
29 White Balance Green Gain j n 00 to FE
30 White Balance Blue Gain j o 00 to FE
31 White Balance Red Offset s x 00 to 7F
32
White Balance Green Offset
s y 00 to 7F
33 White Balance Blue Offset s z 00 to 7F
34 Backlight m g 00 to 64
35 Screen Off k d 00 to 01
36 Tile Mode d d 00 to FF
37 Check Tile Mode d z FF
38 Tile ID d i See Tile ID
39 Natural Mode (In Tile Mode) d j 00 to 01
40 Tile H Position d e 00 to 32
41 Tile V Position d f 00 to 32
42 Tile H Size d g 00 to 32
43 Tile V Size d h 00 to 32
44 DPM Mode Settings f j 00 to 07
45 DPM Wake Up Control s n, 0b 00 to 07
46
Remote Control/Local Key
Operation Lock
k m 00 to 01
47 Power On Delay f h 00 to FA
48 Select Fail Over Mode m i 00 to 02
49 Select Fail Over Input m j See Select Fail Over Input
50 Remote Control Key Lock t p 00 to 02
