LG 47TS30MF - Unpacking and Cabling for 47 TS30 MF

7
ENG
ENGLISH
INSTALLATIONPREPARATION
1
 Liftupthecoverofthebox.
2
 Removethetoppackaging.
3
 Holdbothsidesoftheproductandliftitup.
5
 Placeasoftclothonthetableandputthe
productdownwiththescreenfacingdownward.
4
 Removethepolybag.
6
 ConnecttheLVDScable(Additionalassembly
isrequired).AscalerboardorLVDScableis
optionalandnotprovidedwiththeproduct.
47TS30MF

Pleasereferto"LVDSPinMapGuide"onpages16to18fortheLVDScableassembly.
