LG 47WFB - Lvds Pin Map Guide

26
ENG
ENGLISH
Pin No. Symbol Description NOTE
1 V
LCD
Power Supply+12.0V 1
2 V
LCD
Power Supply+12.0V 1
3 V
LCD
Power Supply+12.0V 1
4 V
LCD
Power Supply+12.0V 1
5 GND Ground
6 GND Ground
7 R2DP Second LVDS receiver signal (D+)
8 GND Ground
9 R2DN Second LVDS receiver signal (D-)
10 R2CLKP Second LVDS receiver clock signal (+)
11 GND Ground
12 R2CLKN Second LVDS receiver clock signal (-)
13 R2CP Second LVDS receiver signal (C+)
14 GND Ground
15 R2CN Second LVDS receiver signal (C-)
16 R2BP Second LVDS receiver signal (B+)
17 GND Ground
18 R2BN Second LVDS receiver signal (B-)
19 R2AP Second LVDS receiver signal (A+)
20 GND Ground
21 R2AN Second LVDS receiver signal (A-)
22 GND Ground
23 R1DP First LVDS receiver signal (D+)
24 GND Ground
25 R1DN First LVDS receiver signal (D-)
26 R1CLKP First LVDS receiver clock signal (+)
27 GND Ground
28 R1CLKN First LVDS receiver clock signal (-)
29 R1CP First LVDS receiver signal (C+)
30 GND Ground
31 R1CN First LVDS receiver signal (C-)
32 R1BP First LVDS receiver signal (B+)
33 GND Ground
34 R1BN First LVDS receiver signal (B-)

47/49/55WFB LVDS connector: DD4RA40JA1 or equivalent

LVDS cable connector: DD4PA40MA1 or equivalent

Cable specification: Coaxial cable or twisted pair cable 1 meter long or shorter
LVDS PIN MAP GUIDE
