LG 49LX560H Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5. Video resolutions
5.1. HDMI Input(PC/DTV)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
PC DDC
1
640*350 31.468 70.09 25.17
EGA X
2
720*400 31.469 70.08 28.32
DOS O
3
640*480 31.469 59.94 25.17
VESA(VGA) O
4
800*600 37.879 60.31 40.00
VESA(SVGA) O
5
1024*768 48.363 60.00 60.00
VESA(XGA) O
6
1152*864 54.348 60.053
VESA X
7
1280*1024 63.981 60.020 108.0
VESA (SXGA) O
8
1360*768 47.712 60.015 85.50
VESA (WXGA) O
9
1920*1080 67.50 60.00 148.5
HDTV 1080P O
DTV
1 720*480 31.500 60.000 27.027 SDTV 480P
2 720*480 31.470 59.940 27.000 SDTV 480P
3 1280*720 45.000 60.000 74.250 HDTV 720P
4 1280*720 44.960 59.940 74.176 HDTV 720P
5 1920*1080 33.750 60.000 74.250 HDTV 1080I
6 1920*1080 33.720 59.940 74.176 HDTV 1080I
7 1920*1080 67.500 60.000 148.500 HDTV 1080P
8 1920*1080 67.4320 59.940 148.352 HDTV 1080P
9 1920*1080 27.000 24.000 74.250 HDTV 1080P
10 1920*1080 26.970 23.976 74.176 HDTV 1080P
11 1920*1080 33.750 30.000 74.250 HDTV 1080P
12 1920*1080 33.710 29.970 74.176 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
PC DDC
1 640*350 31.468 70.09 25.17 EGA Х
2 720*400 31.469 70.08 28.32 DOS O
3 640*480 31.469 59.94 25.17 VESA(VGA) O
4 800*600 37.879 60.31 40.00 VESA(SVGA) O
5 1024*768 48.363 60.00 65.00 VESA(XGA) O
6 1280*768 47.776 59.870 79.5 CVT(WXGA) Х
7 1360*768 47.712 60.015 85.50 VESA (WXGA) Х
8 1600*1200 75.00 60.00 162.0 VESA (UXGA) X
9 1920*1080 67.50 60.00 148.5 HDTV 1080P O
5.2. RGB input(PC)
