LG 49LX761H Service Manual

- 8 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5
Scart (1EA) PAL, SECAM Scart jack is Full scart and support
ATV/DTV-OUT
(not support DTV Auto AV)
6 Head phone out Antenna, AV, HDMI1, HDMI2, USB1,
USB2
7 HDMI Input (2EA) HDMI1-DTV
HDMI2-DTV
Support HDCP
8 SPDIF out (1EA) SPDIF out
9 USB (2EA) EMF, DivX HD, For SVC (download) JPEG, MP3, DivX HD
10 Ethernet Connect (2EA) Ethernet Connect
11 PCMCIA Card slot
(1EA)
PCMCIA slot
12 Speaker Out (2EA) External Volume,
External Volume Control
13 LAN LAN
AUX LAN
Digital TV
(Depending on Country)
Analogue TV
(Depending on Country)
Televison System DVB-T/T2
DVB-C
DVB-S/S2
PAL/SECAM B/G/I/D/K
SECAM L/L’
Programme Coverage VHF, UHF
C-Band, Ku-Band
VHF:E2 to E12, UHF : E21 to E69,
CATV : S1 to S20, HYPER : S21 to S47
Maximum number of
storable programmes
DVB-S/S2 : 6,000
DVB-T/T2/C & Analogue TV : 1,500
External Antenna Impedance 75 Ω
* RF receiving coverage
