- 9 -

Only for training and service purposes

5. External Input Support Format

5.1. HDMI input

No. Resolution H-freq(kHz) V-freq.(Hz) Proposed Remark

DTV

1 720*480 31.47 59.94 SDTV 480P

2 720*480 31.5 60 SDTV 480P

3 720*576 31.25 50 SDTV 576P

4 1280*720 44.96 59.94 HDTV 720P

5 1280*720 45 60 HDTV 720P

6 1280*720 37.5 50 HDTV 720P

7 1920*1080 28.125 50 HDTV 1080I

8 1920*1080 33.72 59.94 HDTV 1080I

9 1920*1080 33.75 60.00 HDTV 1080I

10 1920*1080 26.97 23.976 HDTV 1080P

11 1920*1080 27.00 24.000 HDTV 1080P

12 1920*1080 33.71 29.97 HDTV 1080P

13 1920*1080 33.75 30.00 HDTV 1080P

14 1920*1080 56.25 50.00 HDTV 1080P

15 1920*1080 67.432 59.94 HDTV 1080P

16 1920*1080 67.5 60.00 HDTV 1080P

1 640 x 350 @70Hz 31.46 70.09 EGA

2 720 x 400 @70Hz 31.46 70.08 DOS

3 640 x 480 @60Hz 31.46 59.94 VESA(VGA)

4 800 x 600 @60Hz 37.87 60.31 VESA(SVGA)

5 1024 x 768 @60Hz 48.36 60.00 VESA(XGA)

6 1152 x 864 @60Hz 54.34 60.05 VESA

7 1280 x 1024 @60Hz 63.98 60.02 VESA(SXGA) FHD only

8 1360 x 768 @60Hz 47.71 60.01 VESA(WXGA)

9 1920 x 1080 @60Hz 67.5 60.00 WUXGA(CEA 861D) FHD only
