LG 49WFB - 47;55 WFB LVDS Connection

13
ENG
ENGLISH
47/55WFB LVDS connection
1
Place a soft cloth on the table and put the set on it as illustrated.
2
Put a LVDS cable in a holder. Cable head has to be properly oriented.

To prevent the LVDS cable from being separated, you must use a LVDS holder.

Check the direction of the LVDS cable to prevent damage to the LVDS cable.
CAUTION
