LG 50PJ2 Series User Manual

86
APPENDIX
APPENDIX
04. Volume Mute (Command: k e)
► To control volume mute on/off.
You can also adjust mute using the MUTE button
on remote control.
Transmission
Data 00 : Volume mute on (Volume off)
01 : Volume mute off (Volume on)
[k][e][ ][Set ID][ ][Data][Cr]
Acknowledgemnt
[e][ ][Set ID][ ][OK/NG][Data][x]
02. Aspect Ratio ( Command: k c) (Main Picture Size)
► To adjust the screen format. (Main picture format)
You can also adjust the screen format using the
Aspect Ratio in the PICTURE menu.
Transmission
Data 01 : Normal screen (4:3)
02 : Wide screen (16:9)
04 : Zoom
10~1F : Cinema Zoom 1~16
Data 06 : Original
07 : 14 : 9
09 : Just Scan
[k][c][ ][Set ID][ ][Data][Cr]
Acknowledgemnt
* Using the RGB-PC, Component or HDMI input, you
select either 16:9 or 4:3 screen aspect ratio.
* In HDMI/Component (over 720p)mode, Just Scan is
available.
[c][ ][Set ID][ ][OK/NG][Data][x]
03. Screen Mute (Command: k d)
► To select screen mute on/off.
Transmission
Data 00 : Screen mute off (Picture/Panel on)
01 : Screen mute on (Panel off)
10 : Video mute on (Picture Off)
* In case of Video-Out mute on only, TV will display On
Screen Display(OSD) But, In case of Screen Mute
On, TV will not display OSD.
[k][d][ ][Set ID][ ][Data][Cr]
Acknowledgemnt
[d][ ][Set ID][ ][OK/NG][Data][x]
05. Volume Control (Command: k f)
► To adjust volume.
You can also adjust volume with the VOLUME
buttons on remote control.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 88.
[k][f][ ][Set ID][ ][Data][Cr]
Acknowledgemnt
[f][ ][Set ID][ ][OK/NG][Data][x]
06. Contrast (Command: k g)
► To adjust screen contrast.
You can also adjust contrast in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 88.
[k][g][ ][Set ID][ ][Data][Cr]
[g][ ][Set ID][ ][OK/NG][Data][x]
07. Brightness (Command: k h)
► To adjust screen brightness.
You can also adjust brightness in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 88.
[k][h][ ][Set ID][ ][Data][Cr]
Acknowledgemnt
[h][ ][Set ID][ ][OK/NG][Data][x]
01. Power (Command: k a)
► To control Power On/Off of the TV.
Transmission
Data 00 : Power Off 01 : Power On
Acknowledgemnt
[a][ ][Set ID][ ][OK/NG][Data][x]
► To show Power On/Off.
Transmission
[k][a][ ][Set ID][ ][FF][Cr]
Acknowledgemnt
* If there is the time delay between command and ack
message during power on sequence, It should
be described like “Note: In this model, TV will send
the Acknowledge after power on processing com-
pletion.There might be a time delay between com-
mand and acknowledge.”
[a][ ][Set ID][ ][OK/NG][Data][x]
Acknowledgemnt
[k][a][ ][Set ID][ ][Data][Cr]
