5
EXTERNAL EQUIPMENT SETUP
1
CONNECTING WITH A RCA CABLE
► If you have a mono VCR, connect the audio cable from the
VCR to the AUDIO L/MONO jack of the TV.
NOTE
Camcorder
Video Game Set
or
1
Connect the AUDIO/VIDEO jacks between TV
and VCR or external equipment. Match the jack
colours (Video = yellow, Audio Left = white, and
Audio Right = red)
2
Insert a video tape into the VCR and press
PLAY on the VCR. (Refer to the VCR owner’s
manual.)
Or, Operate the corresponding external equip-
ment.
(Refer to external equipment operating guide.)
3
Select AV1 input source using the INPUT but-
ton on the remote control.
If connected to AV IN2, select AV2 input
source.
To Next Page
