7
EXTERNAL EQUIPMENT SETUP
1
2
CONNECTING WITH A D-SUB 15 PIN CABLE
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's
settings.
1
Connect the RGB output of the PC to the RGB
IN (PC) jack on the TV.
2
Connect the PC audio output to the AUDIO IN
(RGB/DVI) jack on the TV.
3
Turn on the PC and the TV.
4
Select RGB input source using the INPUT but-
ton on the remote control.
(Except 42/50PJ***)
To Next Page
