13. Trouble shooting - USB connection error
Check USB jack
(JK4300 or JK4302 or JK4303)
Y
N
N
Check USB device
If device is 2.5 inch HDD,
Check power adaptor
Replace Jack
Check 5V voltage level at Bead or Jack
Y
Replace one of
IC4303(USB1) or IC4306(USB2/3) and then check
N
Maybe IC4200(USB1/2) or IC100(USB1/2/3)
has problems. Replace It.
• Exception
- USB power could be disabled by inrushing current
- In this case, remove the device and try to reboot the TV (AC power off/on)
Copyright ⓒ 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
