14. Trouble shooting - Ethernet connection error
Replace LAN Port JK 5000
N
Check LAN Port JK 5000
Y
Check PHY IC 5200
N
Replace PHY IC 5200
Y
Check LAN Cable
Recheck
LAN Cable
N
Y
Check MAC Address
Replace
Main B/D
N
Y
Check RMII Rx/Tx Signal Line
R 5206 / R 5207 / R 108 / R 106
N
Replace R 5206 / R 5207 / R 108 /
R 106
Y
Check L9-D chip IC 100
N
Replace IC 100 or Main Board
