SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied to the LED TV used LA5ZC chassis
2. Test condition
Each part is tested as below without special notice.
(1) Temperature : 25 ºC ± 5 ºC(77±9ºF), CST : 40 ºC±5 ºC
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
Standard input voltage (100~240V@ 50/60Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 20 minutes prior
to the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Demanded other specification
- Safety : UL, CSA, CE, IEC specification
- EMC : FCC, ICES, CE, IEC specification
- Wireless : Wireless HD Specification (Option)
4. Model Specification
No Item Specication Remark
1 Market North America
2 Broadcasting system ATSC / NTSC-M, 64 & 256 QAM
3 Available Channel 1) VHF : 2~13
2) UHF : 14~69
3) DTV : 2-69
4) CATV : 1 ~ 135
5) CADTV : 1 ~ 135
4 Receiving system Digital : ATSC, 64 & 256 QAM
Analog : NTSC-M
5 Video Input NTSC-M Rear RCA & Gender
6 Component Input Y/Cb/Cr, Y/ Pb/Pr Rear RCA & Gender
7 HDMI Input HDMI 1 DTV format, Support HDCP2.2/ PC
(HDMI version 1.4/2.0)
Side
HDMI 2 DTV format, Support HDCP2.2/ PC
(HDMI version 1.4/2.0)
Side, Support ARC only HDMI2
HDMI 3 DTV format, Support HDCP2.2/ PC
(HDMI version 1.4)
Side
8 Audio Input Component / AV Audio L/R Input ; Rear
Component and av use same jack ; Rear
9 SPDIF out(1EA) Optical Audio out Rear (1EA),
10 USB Input(3EA) EMF, DivX HD, For SVC (download) Side JPEG, MP3, DivX HD
Support USB3.0 only USB1
To Next Page
