33. [Backlight] (Command: m g)
Adjusts the backlight brightness.
Transmission
(m)(g)( )([Set ID])( )(Data)(Cr)
Data 00 to 64: [Backlight] 0 to 100
Acknowledgment
(g)( )([Set ID])()(OK/NG)(Data)(x)
34. [Screen Off] (Command: k d)
Turns off/off the screen.
Transmission
(k)(d)( )([Set ID])( )(Data)(Cr)
Data 00: Screen On
01: Screen Off
Acknowledgment
(d)( )([Set ID])( )(OK/NG)(Data)(x)
* This feature may not be supported on some models.
35. [Tile Mode] (Command: d d)
Sets a tile mode and values for the tile rows and columns.
Transmission
(d)(d)( )([Set ID])( )(Data)(Cr)
Data 00 to FF: the first byte - tile column
The second byte - tile row
* 00, 01, 10, and 11 mean that the tile mode is off
* The maximum value may differ depending on the model.
Acknowledgment
(d)( )([Set ID])( )(OK/NG)(Data)(x)
* This feature may not be supported on some models.
* Video wall models require to be rebooted for the normal
operation after the values are changed.
36. Check [Tile Mode] (Command: d z)
Checks the tile mode.
Transmission
(d)(z)( )([Set ID])( )(Data)(Cr)
Data FF: Checks [Tile Mode]
Acknowledgment
(z)( )([Set ID])( )(OK/NG)(Data1)(Data2)(Data3)(x)
Data1 00: [Tile Mode] Off
01: [Tile Mode] on
Data2 00 to 0F: tile column
Data3 00 to 0F: tile row
* This feature may not be supported on some models.
37. [Tile ID] (Command: d i)
Sets the tile ID value of the product.
Transmission
(d)(i)( )([Set ID])( )(Data)(Cr)
Data 01 to E1: [Tile ID] 1 to 225
FF: Checks the [Tile ID]
* The data value cannot exceed the value of row x column.
Acknowledgment
(i)( )([Set ID])( )(OK/NG)(Data)(x)
* If you enter a value that exceeds the value of row x column
for the Data parameter, Ack becomes NG.
* This feature may not be supported on some models.
* Video wall models require to be rebooted for the normal
operation after the values are changed.
38. [Natural Mode] (In Tile Mode) (Command: d j)
To display the image naturally, the part of the image that
would normally be displayed in the gap between the monitors
is omitted.
Transmission
(d)(j)( )([Set ID])( )(Data)(Cr)
Data 00: [Off]
01: [On]
Acknowledgment
(j)( )([Set ID])( )(OK/NG)(Data)(x)
* This feature may not be supported on some models.
