LG 55VX1D - External Equipment Setup; Tiling Displays

ENGLISH
15
External Equipment Setup
IR RECEIVER
This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via
an RS-232C cable.
Tiling Displays
How to Mount the Set
Example of 2 x 2 Tiling
Using the screws for attaching the VESA wall mount, mount the set to the wall mount plate or the wall.
≤ 6 mm
(0.2 inches)
Screws(15-M4)
600
400
Screws for attaching the
VESA wall mount (M6)
