SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This specification is applied to the LED TV used LA5CK
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC : CE, IEC
4. Model General Specification
No. Item Specication Remarks
1 Receiving System ATSC / NTSC-M / 64 QAM / 256 QAM North America
2 Available Channel
1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~135
5) CADTV : 01~135
3 Input Voltage North America
AC 100 ~ 240V@
50/60Hz
Mark : 110V, 60Hz (N.America)
4 Market North America
5 Screen Size
28 inch Wide (1366 × 768) HD + 60Hz
32 inch Wide (1920 × 1080) FHD + 60Hz
40 inch Wide (1920 × 1080) FHD + 60Hz
43 inch Wide (1920 × 1080) FHD + T120Hz
49 inch Wide (1920 × 1080) FHD + T120Hz
55 Inch Wide (1920 × 1080) FHD + T120Hz
65 Inch Wide (1920 x 1080) FHD + T240Hz
6 Aspect Ratio 16:9
7 Tuning System FS
8 Module
HC275EXN-VSDP1 28LX570H-UA
LC320DUE-FHA3 32LX570H/560H-UA
HC400DUN-VCKN5 40LX570H/560H-UA
LC430EUE-FHM3 43LX570H/560H-UA
LC490EUE-FHM3 49LX570H/560H-UA
LC550EUE-FHM3 55LX570H-UA
LC650EUF-FHM3 65LX570H-UA
9 Operating Environment
1) Temp : 0 ~ 40 deg
2) Humidity : ~ 80 %
10 Storage Environment
1) Temp. : -20 ~ 60 deg
2) Humidity : ~ 85%
