LG 65UR640S User Manual

12
ENGLISH_index
Method of volume control port
(Depending on model)
• Cable Spec.
/ UP / DOWN
Each up/down pins
are connected to CPU
with pull up resistor
respectively.
CPU detects
transition from 3.3V
to level for
volume control.
Network
(Depending on model)
Wired network connection
This TV can be connected to a Pro:Centric server via the port. After
making the physical connection, the TV needs to be set up for network
communication.
Connect the port of the Modem or Router from Pro:Centric server to
the port on the TV.
2 1
Broadband Modem
Pro:Centric Server
Broadband Modem
Pro:Centric Server
Router
Broadband Modem
Connect the port of the Modem or Router to the port on
the TV.
Connect the port of the PC to the port on the TV.
(Depending on model)
• Do not connect a modular phone cable to the port.
• Since there are various connection methods, please follow
the specifications of your telecommunication carrier or
internet service provider.

LG 65UR640S Specifications

General

Product color	Blue
Product design	Digital signage flat panel
Placement supported	Indoor
Panel mounting interface	300 x 300 mm
Touchscreen	-
Display diagonal	65 \
Display brightness	400 cd/m²
Display technology	LED
Contrast ratio (typical)	1200:1
High Dynamic Range (HDR) technology	High Dynamic Range 10 Pro (HDR10 Pro), Hybrid Log-Gamma (HLG)
RMS rated power	20 W
Speaker impedance	8 Ω
Number of built-in speakers	2
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Operating system installed	Web OS
USB ports quantity	1
HDMI ports quantity	3
Package weight	27800 g
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	169 W
Cables included	AC
Remote control type	S-con
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	57.7 mm
Width	1454 mm
Height	838 mm
Weight	21500 g
Depth (with stand)	271 mm
Height (with stand)	899 mm
Weight (with stand)	21800 g
