DISPLAYPORT (PC) Support Mode
Resolution
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
640 x 480 31.469 59.94
800 x 600 37.879 60.317
1024 x 768 48.363 60
1280 x 720 44.772 59.855
1152 x 864 53.783 59.959
1280 x 1024 63.981 60.02
1920 x 1080 67.5 60
3840 x 2160 67.5 30
DISPLAYPORT (DTV) Support Mode
Resolution
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
720 x 480p 31.5 60
720 x 576p 31.25 50
1280 x 720p 37.5 50
1280 x 720p 45 60
1920 x 1080i 28.1 50
1920 x 1080i 33.75 60
1920 x 1080p 56.25 50
1920 x 1080p 67.5 60
3840 x 2160p 67.5 30
SUPERSIGN (PC) Support Mode
Resolution
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
640 x 480 31.469 59.94
800 x 600 37.879 60.317
1024 x 768 48.363 60.004
1152 x 864 54.348 60.053
1280 x 1024 63.981 60.02
1920 x 1080 67.5 60
3840 x 2160 54 24
3840 x 2160 56.25 25
3840 x 2160 67.5 30
COMPONENT Mode
Resolution
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
720 x 480i 15.73 59.94
720 x 480i 15.73 60
720 x 576i 15.625 50
720 x 480p 31.47 59.94
720 x 480p 31.5 60
720 x 576p 31.25 50
1280 x 720 44.96 59.94
1280 x 720 45 60
1280 x 720 45 50
1920 x 1080 28.125 50
1920 x 1080 33.72 59.94
1920 x 1080 33.75 60
1920 x 1080 56.25 50
1920 x 1080 67.5 60
NOTE
• Vertical frequency: The product display functions
by the screen image changing dozens of times
every second like a fluorescent lamp. The vertical
frequency or refresh rate is the number of image
displays per second. The unit is Hz.
• Horizontal frequency: The horizontal interval is the
time taken to display one horizontal line. When 1
is divided by the horizontal interval, the number
of horizontal lines displayed every second can be
tabulated as the horizontal frequency. The unit is
kHz.
