4. Signal Timing (Supporting Resolution)
4.1. DVI/HDMI/DP/OPS (PC Mode)
No. Section Pol. Dot
Clock
[MHz]
Frequency
[kHz]/[Hz]
Total
Cycle
(E)
Display
(A)
Front
Porch(B)
Sync.
(D)
Back
Porch(F)
Resolution Support
1 H(Pixels) + 40.0 37.879 1056 800 40 128 88 800 x 600 O
V(Lines) + 60.317 628 600 1 4 23
2 H(Pixels) - 65.0 48.363 1344 1024 24 136 160 1024 x 768 O
V(Lines) - 60.0 806 768 3 6 29
3 H(Pixels) + 74.5 44.772 1664 1280 64 128 192 1280 x 720 O
V(Lines) + 59.855 748 720 3 5 20
4 H(Pixels) - 85.50 47.712 1792 1366 70 143 213 1366 x 768 O
V(Lines) - 60 798 768 3 3 24
5 H(Pixels) + 108.0 63.981 1688 1280 48 112 248 1280 x 1024 O
V(Lines) + 60.02 1066 1024 1 3 38
6 H(Pixels) + 148.50 67.5 2200 1920 88 44 88 1920 x 1080 O
V(Lines) + 60 1125 1080 4 5 46
7 H(Pixels) + 297.0 67.5 4400 3840 176 88 296 3840 x 2160 HDMI1/2/3,DP
V(Lines) + 30 2250 2160 8 10 72
8 H(Pixels) + 594.0 135 4400 3840 176 88 296 3840 x 2160 HDMI1/2
V(Lines) + 60 2250 2160 8 10 72
4.2. HDMI/DP/OPS (DTV Mode)
No. Resolution H-freq(kHz) V-freq(Hz) Proposed Remark
1 480/60P 31.5 60 EDTV 480p O
2 576/50P 31.25 50 EDTV 576p O
3 720/50P 37.5 50 HDTV 720p O
4 720/60P 45 60 HDTV 720p O
5 1080/50i 28.1 50 HDTV 1080i 50Hz
(For Australian)
O
6 1080/60i 33.75 60 HDTV 1080i 60Hz O
7 1080/50P 56.25 50 HDTV 1080P 50Hz O
8 1080/60P 67.432 59.94 HDTV 1080P 60Hz O
9 1080/60P 67.5 60 HDTV 1080P 60Hz O
10 2160/30P 67.5 30 UD 2160P 30Hz HDMI1/2/3, DisplayPort
11 2160/50P 112.5 50 UD 2160P 50Hz HDMI1/2
12 2160/60P 135 60 UD 2160P 60Hz HDMI1/2
