PREPARATION
ENGLISH
PREPARATION
The Installation Manual provides the necessary information regarding the components, installation
and setting method of AC Smart 5 which the user should have a fair understanding/be aware of.
AC Smart 5 Overview
AC Smart 5 is a central controller installed in management room of a building or administration
room of a school, which can monitor or control the operation of the IDU, ventilation, DI/DO,
DOKIT, system boiler, AHU, and I/O module installed in each room of the building individually or
by integration through touch screen.
AC Smart 5 is a single machine and can be connected to up to 128 devices (indoor unit,
ventilation, DI/DO, DOKIT, system boiler, AHU). Or up to 64 devices (indoor unit, ventilation,
DI/DO, DOKIT, system boiler, AHU) and 9 I/O modules.
Components
The following components are included in the package box. Open the box and verify that all
components are included.
AC Smart 5
Wall installation
plate
Screw
Power Cord
Manual SD Card 8 GB
Power Adapter
NOTE
!
The schematics of the components and optionally purchased products shown may differ
from the actual components and products.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid potential hazards.
CAUTION
!
SD Card provided by LG is for the data backup and recovery when specialized service
technician supports the service, so be careful not to lose it by using it for other purposes.
