118 Multi type Air Conditioner
Control Devices and Function
Test run method
1. Set the wiring of system and indoor unit.
2. Apply power to the setting.
3. Do auto addressing to the outdoor unit.
4. After addressing, initialize the central controller(Manual initialize: Total on + total off + 16 key).
• Cooling: Setting basically(Total On + Total Off + 4 key)
• Heating: Total On + Total Off + 8 key ➡ Red power lamp 'On'
6. Check up On/Off with a related indoor key pressing.
Installation
■ CAUTIONS
• Don’t install near elevator, computer, auto-
matic door. (High noise area).
• Don’t install near high moisture & high oscilla-
tion area.
• Don’t install near direct sunlight or heat
source.
• Don’t operate with wet hands.
• Don’t pull the connected wire.
