228 Multi type Air Conditioner
Exploded View & Replacement Parts List
AMNH09GB1A0 AMNH12GB1A0
PART No.
249951 CONTROL BOX ASSEMBLY(INDOOR) 4995A20821C 4995A20821D
330870 PAN ASSEMBLY, DRAIN AGK30318401 AGK30318401
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20256A 5421A20256A
359012 FAN ASSEMBLY, BLOWER 5901A20056B 5901A20056B
152312 FILTER ASSEMBLY, AIR CLEANER
5231AP3330P 5231AP3330P
346810-1 MOTOR ASSEMBLY, INDOOR 4681A20091L 4681A20091L
346810-2 MOTOR ASSEMBLY, INDOOR 4681A20198A 4681A20198A
268714-1 PWB(PCB) ASSEMBLY MAIN 6871A10354D 6871A10354D
268714-2 PWB(PCB) ASSEMBLY MAIN 6871A20740L 6871A20740L
EEPROM PCB
263230-1 THERMISTOR, NTC 6323AQ3226V 6323AQ3226V
RED(EVA-OUT)
263230-2 THERMISTOR, NTC 6323A10002A 6323A10002A
YELLOW(AIR)
263230-3 THERMISTOR, NTC 6323AQ3226X 6323AQ3226X
WHITE(EVA-IN)
55211G
TUBE ASSEMBLY, MENIFOLD(INDOOR)
5211A21813B 5211A21813B EVA-IN
352118
TUBE ASSEMBLY, MENIFOLD(INDOOR)
5211A21812B 5211A21812B EVA-OUT
267110 REMOTE CONTROLLER ASSEMBLY 6711A20127B 6711A20127B
352150 HOSE ASSEMBLY, DRIAN 5215A20008A 5215A20008A
158591 PUMP ASSEMBLY, WATER 5859A10008A 5859A10008A
LOCATION No.
DESCRIPTION
REMARK
PART LIS T(B1)
To Next Page
