230 Multi type Air Conditioner
Exploded View & Replacement Parts List
AMNH18GB2A0 AMNH24GB2A0
PART No.
249951 CASE ASSEMBLY, CONTROL(INDOOR) 4995A20821E 4995A20821F
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20279B 5421A20280A
359012 FAN ASSEMBLY, BLOWER 5901A20057B 5901A20057B
152312 FILTER ASSEMBLY, AIR CLEANER 5231AP3330Q 5231AP3330Q
346810 MOTOR ASSEMBLY, DC, INDOOR 4681A20198A 4681A20198A
330870 PAN ASSEMBLY, DRAIN AGK30318402 AGK30318402
268714-1 PCB ASSEMBLY, MAIN 6871A10354D 6871A10354D
268714-2 PCB ASSEMBLY, MAIN 6871A20740M 6871A20740N EEPROM PCB
263230-1 THERMISTOR, NTC
6323AQ3226V 6323AQ3226V
RED(EVA-OUT)
263230-2 THERMISTOR, NTC 6323A10002A 6323A10002A YELLOW(AIR)
263230-3 THERMISTOR, NTC 6323AQ3226X 6323AQ3226X WHITE(EVA-IN)
55211G TUBE ASSEMBLY, MENIFOLD(INDOOR) AJR30261002 AJR30261001 EVA-IN
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A11604D 5211A11604D EVA-OUT
267110 REMOTE CONTROLLER ASSEMBLY 6711A20127B 6711A20127B
352150 HOSE ASSEMBLY, DRIAN 5215A20008A 5215A20008A
158591 PUMP ASSEMBLY, WATER 5859A10008A 5859A10008A
130911 CABINET ASSEMBLY INDOOR 3091A10093G 3091A10093G
137211 PANEL ASSEMBLY FRONT 3069A20014K 3069A20014K
LOCATION No.
DESCRIPTION
REMARK
PART LIS T(B2)
