232 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Duct Type - High Static )
PART No.
AMNH186BHA0 AMNH246BHA0 AMNH306BGA0 AMNC306BGA0 AMNH366BGA0
152302 FILTER (MECH), A/C 5230A90002A 5230A90002A 5230A30001L 5230A30001L 5230A30001L R
237210 PANEL ASSEMBLY, UPPER 3721A20177A 3721A20177A 3721A20180A 3721A20180C 3721A20180A R
249951 CONTROL BOX ASSEMBLY(INDOOR) 4995A14002A 4995A14002B 4995A14002C 4995A14002C 4995A14002D R
263230-1 THERMISTOR ASSEMBLY(IN) 6323AQ3226G 6323AQ3226G 6323AQ3226G 6323AQ3226G 6323AQ3226G R
263230-2 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214E 6323AQ3214E 6323AQ3214E 6323AQ3214E 6323AQ3214E R
263230-3 THERMISTOR ASSEMBLY (OUT) 6323AQ3226V 6323AQ3226V 6323AQ3226V 6323AQ3226V 6323AQ3226V R
267110 REMOTE CONTROLLER ASSEMBLY 6711A10008X 6711A10008X 6711A10008X 6711A20043E 6711A10008X R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10140E 6871A10140F 6871A10131H 6871A10131H 6871A10131J R
330860 DRAIN PAN ASSEMBLY 3087A10008B 3087A10008B 3087A10008A 3087A10008A 3087A10008A R
336610-1 HOUSING(MECH), WRAPPER 3660A20017A 3660A20017A 3660A20019A 3660A20019A 3660A20019A R
336610-2 HOUSING(MECH), WRAPPER 3660A20018A 3660A20018A 3660A20020A 3660A20020A 3660A20020A R
346810 MOTOR ASSEMBLY, INDOOR 4681A10013C 4681A10013C 4681A10013J 4681A10013J 4681A10013A R
352111* TUBE ASSEMLBY, CONNECTOR 5211A20514G 5211A20514G 5211A20514J 5211A20514J 5211A20514J R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A20465G 5211A20465G 5211A20416J 5211A20416J 5211A20416J R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20100A 5421A20100B 5421A10027A 5421A10027A 5421A10027A R
359012-1 FAN ASSEMBLY, BLOWER(Single) 5901A10026A 5901A10026A 5901A10026A 5901A10026A 5901A10026A R
359012 FAN ASSEMBLY, BLOWER(Motor) 5901A10028B 5901A10028B 5901A10028J 5901A10028J 5901A10028A R
552111 TUBE ASSEMBLY, CAPILLARY 5211A20466K 5211A20466L 5211A20693D 5211A20693D 5211A20693D R
WOCZZ CAPACITOR, DRAWING 2A00986D 2A00986D 2A00986D 2A00986D 2A00986D R
DESCRIPTION
SVC
CODE
LOCATION
No.
PART No.
AMNC246BHA0 AMNC366BGA0
152302 FILTER(MECH),A/C 5230A30001M 5230A30001L R
237210 PANEL ASSEMBLY,UPPER 3721A20177C 3721A20180C R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A14002B 4995A14002D R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226G 6323AQ3226G R
263230-2 THERMISTOR ASSEMBLY 6323AQ3214E 6323AQ3214E R
263230-3 THERMISTOR ASSEMBLY 6323AQ3226V 6323AQ3226V R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043E 6711A20043E R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10140F 6871A10131J R
330860 DRAIN PAN ASSEMBLY 3087A10008B 3087A10008A R
336600-1 HOUSING (MECH),WRAPPER 3660A20017A 3660A20019A R
336600-2 HOUSING (MECH),WRAPPER 3660A20018A 3660A20020A R
346810 MOTOR ASSEMBLY,INDOOR 4681A10013C 4681A10013A R
352111* SOCKET (MECH),FLARE 5162A20011C 5211A20514J R
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20465G 5211A20416J R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20100B 5421A10027A R
359012-1 FAN,BLOWER 5901A10026A 5901A10026A R
359012 FAN ASSEMBLY,BLOWER 5901A10028B 5901A10028A R
552111 TUBE ASSEMBLY,CAPILLARY 5211A20466L 5211A20693D R
W0CZZ CAPACITOR,DRAWING 2A00986D 2A00986D R
DESCRIPTION
SVC
CODE
LOCATION
No.
NOTE)
*
5211A20514G is for connecting service valve pipe fitting.
