236 Multi type Air Conditioner

Parts List(Built in Duct Type-BP chassis)

Exploded View & Replacement Parts List

237202 PANLE, FRONT 3720A20260B 3720A20260B R

137210 PANEL ASSEMBLY, FRONT (SINGLE) 3721A20168A 3721A20168A R

137214 PANEL, UPPER 3721A20188A 3721A20188A R

152302 FILTER (MECH), A/C 5230A30001R 5230A30001R R

158591 PUMP ASSEMBLY, WATER 5859A20002A 5859A20002A R

249951 CONTROL BOX ASSEMBLY(INDOOR) 4995A20355C 4995A20355B R

263230-1 THERMISTOR ASSEMBLY 6323AQ3226Y 6323AQ3226Y R

263230-2 THERMISTOR ASSEMBLY 6323AQ3214E 6323AQ3214E R

263230-3 THERMISTOR ASSEMBLY 6323AQ3226E 6323AQ3226E R

267110 REMOTE CONTROLLER ASSEMBLY 6711A10008U 6711A10008U R

268714 PWB(PCB) ASSEMBLY, MAIN 6871A10140G 6871A10140H R

330860 DRAIN PAN ASSEMBLY 3086A10036A 3086A10036A R

336610-1 HOUSING(MECH), WRAPPER 3660A20017A 3660A20017A R

336610-2 HOUSING(MECH), WRAPPER 3660A20018A 3660A20018A R

346811 MOTOR ASSEMBLY, INDOOR 4681A10031A 4681A10031A R

352118-1 TUBE ASSEMBLY, MENIFOLD(OUT) 5211A21171A 5211A21171A R

352118-2 TUBE ASSEMBLY, MANIFOLD (IN) 5211A21172A 5211A21172A R

354210 EVAPORATOR ASSEMBLY, FIRST 5421A20178E 5421A20178E R

359012 FAN ASSEMBLY, BLOWE 5901A10049A 5901A10049A

359012-1 FAN ASSEMBLY, BLOWER(SINGLE) 5901A10026A 5901A10026A R

WOCZZ CAPACITOR, DRAWING 2A00986D 2A00986D R

Location

No.

Description

Part No.

AMNH096BPA0 AMNH126BPA0

SVC CODE
