238 Multi type Air Conditioner

Exploded View & Replacement Parts List

Parts List(Cassette Type - 1 way)

135802 DOOR LOCK 3580A20010A 3580A20010A R

268714 PWB(PCB) ASSEMBLY,MAIN 6871A10363C 6871A10363D R

139011 CABINET ASSEMBLY,INDOOR 3091A10024A 3091A10024A R

158580 PUMP ASSEMBLY,WATER 5859A10001A 5859A10001A R

159830 AIR CLEANER ASSEMBLY 5983A10006A 5983A10006A R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10114C 4995A10114D R

263230-1 THERMISTOR ASSEMBLY (IN) 6323AQ3226E 6323AQ3226E R

263230-2 THERMISTOR ASSEMBLY (OUT) 6323AQ3226V 6323AQ3226V R

263230-3 THERMISTOR ASSEMBLY (ROOM) 6323AQ3213E 6323AQ3213E R

266012 SWITCH ASSEMBLY,FLOAT 6601A20001E 6601A20001E R

266090 HVB ASSEMBLY 6690A20009K 6690A20009K R

267110-1 REMOTE CONTROLLER ASSEMBLY 6711A20127A 6711A20127A R

267110-2

REMOTE CONTROLLER ASSEMBLY (WIRELESS)

6711A20096B 6711A20096B Option

330870 DRAIN PAN ASSEMBLY 3087A10005A 3087A10005A R

352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A20229E 5211A20229E R

352116 TUBE ASSEMBLY, EVAPORATOR OUT 5211A20230E 5211A20230E R

354210 EVAPORATOR ASSEMBLY,FIRST 5421A10011A 5421A10011A R

354212 DRAIN ASSEMBLY,TUBE 5251A20001A 5251A20001A R

359011 FAN ASSEMBLY,CROSS FLOW 5901AR2441A 5901AR2441A R

346810 MOTOR ASSEMBLY,INDOOR 4681A20091K 4681A20091K R

135500 COVER 3550A21008A 3550A21008A R

W1SZ AIR GUIDE ASSEMBLY 5239A10004A 5239A10004A R

AMNH09GTCC0 AMNH12GTCC0

LOCATION

No.

DESCRIPTION

Part No.

REMARKS
