Service Manual 243

Exploded View & Replacement Parts List

Parts List(Cassette Type - 4 way - TE(1) 9K, 12K, 18K)

NOTE) 35211* is for pipe fitting the SVC valve.

PART No.

AMNH096TEC0 AMNH126TEC0 AMNH186TEC0 AMNH09GTEF0 AMNH12GTEF0 AMNH18GTEF0

130411 BASE ASSEMBLY,WELD[INDOOR] 3041A10013A 3041A10013A 3041A10013A 3041A10073A 3041A10073A 3041A10073A R

130911-1 CABINET ASSEMBLY,INDOOR 3091A10023C 3091A10023C 3091A10023C 3091A10023E 3091A10023E 3091A10023E R

130911-2 CABINET ASSEMBLY,INDOOR 3091A10023D 3091A10023D 3091A10023D 3091A10023F 3091A10023F 3091A10023F R

158591 PUMP ASSEMBLY,WATER 5859A20001M 5859A20001M 5859A20001M 5859A10007A 5859A10007A 5859A10007A R

159830 AIR CLEANER ASSEMBLY 5983A10002A 5983A10002A 5983A10002A 5983A10002A 5983A10002A 5983A10002A R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20168B 4995A14001D 4995A14001C 4995A10180B 4995A10180C 4995A10180D R

263230-1 THERMISTOR ASSEMBLY (OUT) 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T R

263230-2 THERMISTOR ASSEMBLY (IN) 6323AQ3226F 6323AQ3226F 6323AQ3226F 6323AQ3226N 6323AQ3226F 6323AQ3226F R

263230-3 THERMISTOR ASSEMBLY (ROOM) 6323A10002A 6323A10002A 6323A10002A 6323A10002A 6323A10002A 6323A10002A R

266090 H.V ASSEMBLY 6609A20005C 6609A20005C 6609A20005C 6609A20009J 6609A20009J 6609A20009J R

268714 PWB(PCB) ASSEMBLY,MAIN 6871A10209Z 6871A10158D 6871A10158C 6871A10363E 6871A10363F 6871A10363Y R

267110-1 REMOTE CONTROLLER ASSEMBLY 6711A20076N 6711A20076N 6711A20076N 6711A20127A 6711A20127A 6711A20127A R

267110-2

REMOTE CONTROLLER ASSEMBLY (WIRELESS)

6711A20096B 6711A20096B 6711A20096B - - - R

330870 DRAIN PAN ASSEMBLY 3087A10002A 3087A10002A 3087A10002A 3087A10030D 3087A10030D 3087A10030D R

346810 MOTOR ASSEMBLY,INDOOR 4681AC2026E 4681AC2026E 4681AC2026C 4681A20168B 4681A20168B 4681A20168B R

352111* TUBE ASSEMBLY, CONNECTOR - - 5211A20514G - 5211A20514G 5211A20514G R

352118

TUBE ASSEMBLY,MENIFOLD(INDOOR)

5211A20241S 5211A20241S 5211A20241R 5211A21463D 5211A21463A 5211A21463A R

35211A

TUBE ASSEMBLY, SUCTION (INDOOR)

5211A20243M 5211A20243M 5211A20243M 5211A12312A 5211A21486A 5211A21486A R

352150 DRAIN ASSEMBLY, HOSE 5251A20002A 5251A20002A 5251A20002A 5251A20012A 5251A20012A 5251A20012A R

354211 EVAPORATOR ASSEMBLY,BENDING 5421A10006A 5421A10006A 5421A10006A 5421A10060B 5421A10060A 5421A10060A R

359011 FAN,TURBO 5900A10004A 5900A10004A 5900A10004A 5900A20054A 5900A20054A 5900A20054A R

W0CZZ CAPACITOR,DRAWING 3H00660N 3H00660N 3H00660N - - - R

W4056 LOCKER 4056A20001A 4056A20001A 4056A20001A 4A01405H 4A01405H 4A01405H R

DESCRIPTION

SVC

CODE

LOCATION

No.
