246 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Cassette Type - 4 way - TF 24K, 30K)
NOTE) 35211* is for pipe fitting the SVC valve.
130411 BASE ASSEMBLY,WELD[INDOOR] 3041A10030B 3041A10030B 3041A10030B 3041A10030B R
130911-1 CABINET ASSEMBLY,INDOOR 3091A10051A 3091A10051A 3091A10051A 3091A10051C R
130911-2 CABINET ASSEMBLY,INDOOR 3091A10051B 3091A10051B 3091A10051B 3091A10051D R
137211 PANEL ASSEMBLY,FRONT(INDOOR) 3721A10072E 3721A10072E - - R
135314 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10211C 3531A10211C - - R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A R
152312 FILTER ASSEMBLY, AIR CLEANER 5231A10012A 5231A10012A - - R
158591 PUMP ASSEMBLY,WATER 5859A20001K 5859A20001K 5859A20001K 5859A20001K R
159830 AIR CLEANER ASSEMBLY 5983A10002A 5983A10002A 5983A10002A 5983A10002A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10093K 4995A10093N 4995A10093N 4995A10131D R
263230-1 THERMISTOR ASSEMBLY (OUT) 6323AQ3226Y 6323AQ3226Y 6323AQ3226Y 6323AQ3226Y R
263230-2 THERMISTOR ASSEMBLY (IN) 6323AQ3226E 6323AQ3226E 6323AQ3226E 6323AQ3226E R
263230-3 THERMISTOR ASSEMBLY (ROOM) 6323A10002A 6323A10002A 6323A10002A 6323A10002A R
266012 SWITCH ASSEMBLY,FLOAT 6601A20001H 6601A20001H 6601A20001H 6601A20001H R
266090 H.V ASSEMBLY 6609A20005E 6609A20005E 6609A20005E 6609A20005E R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20096J 6871A20096J - - R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10158B 6871A10158R 6871A10158R 6871A10338W R
267110-1 REMOTE CONTROLLER ASSEMBLY 6711A20076N 6711A20076N 6711A20076N 6711A20076K R
267110-2
REMOTE CONTROLLER ASSEMBLY (WIRELESS)
6711A20096B 6711A20096B 6711A20096B - option
330870 DRAIN PAN ASSEMBLY 3087A10010B 3087A10010B 3087A10010B 3087A10010B R
346810 MOTOR ASSEMBLY,INDOOR 4681A20051Z 4681A20051W 4681A20051W 4681A20051W R
352111* TUBE ASSEMBLY, CONNECTOR 5211A20514G 5211A20514J 5211A20514J 5211A20514J R
352118-1 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20251Q 5211A20251Q 5211A20251U 5211A20251U R
352118-2 TUBE ASSEMBLY, MANIFOLD (INDOOR) 5211A20251K 5211A20251K 5211A20251K 5211A20251K R
552111 TUBE ASSEMBLY, CAPILLARY (INDOOR) 5211A21137B 5211A21137B 5211A21137B 5211A21137B R
352150 DRAIN ASSEMBLY, TUBE 5251A20002B 5251A20002B 5251AP2984A 5251A20002B R
354211-1 EVAPORATOR ASSEMBLY,BENDING 5421A10016G 5421A10016G 5421A10016G 5421A10016G R
354211-2 EVAPORATOR ASSEMBLY, BENDING 5421A10016H 5421A10016H 5421A10016H 5421A10016H R
359012 FAN,TURBO 5901A10036A 5901A10036A 5901A10036A 5901A10036A R
W0CZZ CAPACITOR,DRAWING 3H00660M 3H00660M 3H00660M 3H00660M R
W4056 LOCKER 4056A20001B 4056A20001B 4056A20001B 4056A20001B R
AMNH246TFC0 AMNH306TFC0 AMNH306TFA0 AMNC306TFC0
LOCATION
No.
DESCRIPTION
Part No.
REMARKS
To Next Page
