Service Manual 249

Parts List(Cassette Type - 4 way - TH)

PART No.

AMNH24GTHF0

130411 BASE ASSEMBLY,WELD[INDOOR] 3041A10069A R

130911-1 CABINET ASSEMBLY, INDOOR 3091A10085A R

130911-2 CABINET ASSEMBLY, INDOOR 3091A10075A R

130911-3 CABINET ASSEMBLY, INDOOR 3091A10075B R

158591 PUMP ASSEMBLY,WATER 5859A10006C R

159830 FILTER ASSEMBLY, AIR CLEANER 5983A10003D R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A11007W R

263230-1 THERMISTOR ASSEMBLY (OUT) 6323A30002A R

263230-2 THERMISTOR ASSEMBLY (IN) 6323AQ3226W R

263230-3 THERMISTOR ASSEMBLY (ROOM) 6323A10002B R

266012 SWITCH ASSEMBLY,FLOAT 6601A20001K R

266090 H.V ASSEMBLY 6609A20009L R

268714 PWB(PCB) ASSEMBLY,MAIN 6871A10363G R

267110-1 REMOTE CONTROLLER ASSEMBLY 6711A20127A R

267110-2 REMOTE CONTROLLER ASSEMBLY (WIRELESS) - R

330870 DRAIN PAN ASSEMBLY 3087A10035F R

346810 MOTOR ASSEMBLY,INDOOR 4681A20168A R

352118-1 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A10600A R

352118-2 TUBE ASSEMBLY, MANIFOLD (INDOOR) - R

552111 TUBE ASSEMBLY, CAPILLARY (INDOOR) 5211A10550B R

354211-1 EVAPORATOR ASSEMBLY,BENDING 5421A10061A R

354211-2 EVAPORATOR ASSEMBLY, BENDING - R

359011 FAN,TURBO 5900A10016A R

W4056 LOCKER 4A01405C R

DESCRIPTION

SVC

CODE

LOCATION

No.

NOTE) 35211* is for pipe fitting the SVC valve.

Exploded View & Replacement Parts List
