LG AMNH12GD4L0 User Manual

252 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Cassette Type - 4 way - TD 36K)
PART No.
AMNH366TDC0 AMNC366TDC0
130411 BASE ASSEMBLY,WELD[INDOOR] 3041A10016A 3041A10016A R
130911-1 CABINET ASSEMBLY, INDOOR 3091A10030A 3091A20034A R
130911-2 CABINET ASSEMBLY, INDOOR 3091A10030B 3091A20034B R
130912-1 CABINET ASSEMBLY, INDOOR 3091A10031A 3091A20035A R
130912-2 CABINET ASSEMBLY, INDOOR 3091A10031B 3091A20035B R
137211 PANEL ASSEMBLY,FRONT(INDOOR) 3721A10106B - R
135314 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10066A - R
135802 DOOR ROCK 3580A20005A - R
146811 MOTOR ASSEMBLY,STEP 4681A20055A - R
152312 FILTER ASSEMBLY, AIR CLEANER 5231A10004A - R
158591 PUMP ASSEMBLY,WATER 5859A20001D 5859A20001D R
159830 AIR CLEANER ASSEMBLY 5983A10003D 5983A10003D R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A22004L 4995A22004U R
263230-1 THERMISTOR ASSEMBLY (OUT) 6323AQ3226V 6323AQ3226T R
263230-2 THERMISTOR ASSEMBLY (IN) 6323AQ3226A 6323A30002A R
263230-3 THERMISTOR ASSEMBLY (ROOM) 6323A10002B 6323A10002B R
266012 SWITCH ASSEMBLY,FLOAT 6601A20001F 6601A20001F R
266090 H.V ASSEMBLY 6609A20005D 6609A20005H R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20096J - R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10158S 6871A10338X R
267110-1 REMOTE CONTROLLER ASSEMBLY 6711A20076N 6711A20076K R
267110-2 REMOTE CONTROLLER ASSEMBLY (WIRELESS) 6711A20096B - R
330870 DRAIN PAN ASSEMBLY 3087A10006A 3087A10006A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20006J 4681A20006J R
352111* TUBE ASSEMBLY, CONNECTOR 5211A20514J 5211A20514J R
352118-1 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20251R 5211A20251R R
352118-2 TUBE ASSEMBLY, MANIFOLD (INDOOR) 5211A20251B 5211A20251B R
552111 TUBE ASSEMBLY, CAPILLARY (INDOOR) 5211A20316M 5211A20316M R
354211-1 EVAPORATOR ASSEMBLY,BENDING 5421A10016A 5421A10016A R
354211-2 EVAPORATOR ASSEMBLY, BENDING 5421A10016B 5421A10016B R
359011 FAN,TURBO 5900A10003B 5900A10003B R
738282 MANUAL, INSTALLATION 3828A20403F -
738290 MANUAL,OWNERS 3828A20394D - R
W0CZZ CAPACITOR,DRAWING 3H00660M 3H00660M R
W4056 LOCKER 4056A20001B 4056A20001B R
DESCRIPTION
SVC
CODE
LOCATION
No.
NOTE) 35211* is for pipe fitting the SVC valve.
