LG AMNH12GD4L0 User Manual

254 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Convertible Type-VE chassis)
LOCATION
DESCRIPTION
PART No.
SVC CORD
No.
137211 PANEL ASSEMBLY,FRONT(INDOOR) 3721A10092A 3721A10092A 3721A10092A 3721A10092A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
147581 LOUVER,HORIZONTAL 4758A10006A 4758A10006A 4758A10006A 4758A10006A R
152302 FILTER(MECH),A/C 5230A10009A 5230A10009A 5230A10009A 5230A10009A R
159830 AIR CLEANER ASSEMBLY - 5983A20007F - 5983A20007F R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20356F 4995A20356 4995A20356E 4995A20356 R
263230-1 THERMISTOR ASSEMBLY (IN, ROOM) 6323A20004T 6323A20004T 6323A20004T 6323A20004T R
263230-2 THERMISTOR ASSEMBLY (OUT) 6323AQ3226V 6323AQ3226V 6323AQ3226V 6323AQ3226V R
266000 SWITCH,PUSH 6600AP2059B 6600AP2059B 6600AP2059B 6600AP2059B R
266090 H.V ASSEMBLY - 6609A10003S - 6609A10003S R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20096A 6711A20096A 6711A20096A 6711A20096A R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20390D 6871A20390D 6871A20390D 6871A20390D R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20359B 6871A20359B 6871A20359B 6871A20359B R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20358E 6871A20358 6871A20358F 6871A20358 R
330780 HOUSING 3078A20001A 3078A20001A 3078A20001A 3078A20001A R
330870 DRAIN PAN ASSEMBLY 3087A10018A 3087A10018A 3087A10018A 3087A10018A R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20131B 4681A20131B 4681A20131A 4681A20131A R
35211B TUBE ASSEMBLY,TUBING 5211A21217B 5211A21217B 5211A21217B 5211A21217B R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575Q 5251AR2575Q 5251AR2575Q 5251AR2575Q R
354211 EVAPORATOR ASSEMBLY,FIRST 5421A30019B 5421A30019B 5421A30019B 5421A30019B R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20008E 5901A20008E 5901A20008E 5901A20008E R
733010 PLATE ASSEMBLY,INSTALL 3301A10002A 3301A10002A 3301A10002A 3301A10002A R
W0CZZ CAPACITOR,DRAWING 3H00671A 3H00671A 3H00671A 3H00671A R
W4810 BRACKET 4810A21019A 4810A21019A 4810A21019A 4810A21019A R
131410 CHASSIS ASSEMBLY 3141A10009A 3141A10009A 3141A10009A 3141A10009A R
135500 COVER 3550A30201A 3550A30201A 3550A30201A 3550A30201A R
135310 GRILL ASSEMBLY, DIFFUSER(INDOOR) 3531A10248A 3531A10248A 3531A10248A 3531A10248A R
135313 GRILL ASSEMBLY, INLET 3531A10247A 3531A10247A 3531A10247A 3531A10247A R
AMNH096VEA0 AMNH096VEL0 AMNH126VEA0 AMNH126VEL0
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
