LG AMNH12GD4L0 User Manual

260 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Single compressor inverter)
NOTE) 35211* is for pipe fitting the SVC valve.
263230-1 THERMISTOR ASSEMBLY 6323A20037A 6323A20037A 6323A20037A R
263230-2 THERMISTOR ASSEMBLY 6323A20037B 6323A20037B 6323A20037B R
430410 BASE ASSEMBLY,OUTDOOR 3041A20066A 3041A20066A 3041A20066A R
435301 GRILLE,DISCHARGE 3530A20006G 3530A20006G 3530A20006G R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30115G 3551A30115G 3551A30115G R
437210 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A20027Q 3721A20027Q 3721A20027Q R
437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3721A20026Y 3721A20026Y 3721A20026Y R
447910 BARRIER ASSEMBLY,OUTDOOR 4791A30002G 4791A30002G 4791A30002G R
546810 MOTOR ASSEMBLY,OUTDOOR 4681A20170A 4681A20170A 4681A20170A R
552112 TUBE ASSEMBLY,CONDENSER IN 5211A23331A 5211A23331A 5211A23331A R
552113-1 TUBE ASSEMBLY,CONDENSER OUT 5211A23336A 5211A23332A 5211A23336A R
552113-2 TUBE ASSEMBLY,CONDENSER OUT 5211A23337A 5211A20927D 5211A23337A R
552116 TUBE ASSEMBLY,REVERSING 5211A23335A 5211A23330A 5211A23335B R
552203-1 VALVE,SERVICE 5220A20001K 5220A20001K 5220A20001K R
552203-2 VALVE,SERVICE 2H02479J 2H02479J 2H02479J R
552204-1 HARNESS 6877A20050N 6877A20050N 6877A20050N R
552204-2 HARNESS 6877A20050P 6877A20050P 6877A20050P R
554031 CONDENSER ASSEMBLY,BENT 5403A20221A 5403A20221A 5403A20221A R
554160 COMPRESSOR SET 5416A90029A 2520UGHN2AC 5416A90015A R
558511 DRIER ASSEMBLY 5851A20003J - 5851A20003J R
559010 FAN ASSEMBLY,PROPELLER 5901A10033A 5901A10033A 5901A10033A R
561410 COIL ASSEMBLY,REVERSING VALVE 6141AR3509L 6141AR3509L 6141AR3509L R
661400 COIL ASSEMBLY,EXPANSION 6140A90001K 6140A90001K 6140A90001K R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A21016B 4995A21016A 4995A21016C R
261704 REACTOR 5874A90003A 5874A90003A 5874A90003A R
268711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10334A 6871A10225A 6871A10334B R
668713 PWB(PCB) ASSEMBLY, SUB (CENTRAL CONTROL) 6871A20484A 6871A20484A 6871A20484A OPTION
W0CZZ CAPACITOR,DRAWING 3A02157A 3A02157A 3A02157A R
Location
No.
Description
Part No.
A2UW146FA2 A2UW166FA0 A2UW166FA1
SVC
CODE
