LG AMNW07GDBL1 User Manual

- 2 -
Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. Specification
Indoor
Note:
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB/19°C(66.2°F) WB
- Outdoor Temperature 35°C(95°F) DB/24°C(75.2°F) WB
Heating: - Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB
- Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) WB
Piping Length - Interconnecting Piping Length 7.5m
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national code.
3. The specification may be subject to change without prior notice for purpose of improvement.
Conversion Formula
kW = Btu/h x 0.0002931
cfm = CMM x 35.3
Power Supply Ø, V, Hz
Capacity(*) Btu/h Class
Current Running Current A
Fan Motor Type
Fan Type
Motor Output(W) x No. of Unit
Air Flow Rate CMM
(H / M / L) CFM
External Static Pressure mmAq
Capacitor μF / Vac
Drive
Coil Row x Column x FPI
Dimensions Body mm
(W x H x D) inch
Decorative Panel mm
inch
Net Weight Body kg (lbs)
Decorative Panel kg (lbs)
Air Filter
Sound Level (H / M / L) dB(A)+3
Piping Liquid mm (inch)
Connections Gas mm (inch)
Drain(OD/ID) mm(inch)
Dehumidification Rate l/h
Safety Devices
Temperature Sensor
Refrigerant
Refrigerant Control
Transmission Interunit Cable No. x AWG
Model
AMNW07GDBL1
[LMN077HVT]
AMNW09GDBL1
[LMN097HVT]
1, 208/230, 60 1, 208/230, 60
7,000 9,000
0.2 0.2
BLDC BLDC
Cross Flow Fan Cross Flow Fan
14.4 x 1 14.4 x 1
5.6 / 5.0 / 4.6 7.0 / 6.5 / 6.0
198 / 177 / 162 247 / 230 / 212
--
--
Direct Drive Direct Drive
2R x 16C x 23 2R x 16C x 23
895 x 289 x 210 895 x 289 x 210
35-1/4 x 11-3/8 x 8-9/32 35-1/4 x 11-3/8 x 8-9/32
--
--
9.5(20.9) 9.5(20.9)
--
Long Life Filter Long Life Filter
33 / 30 / 26 33 / 30 / 27
6.35 (1/4) 6.35 (1/4)
9.52 (3/8) 9.52 (3/8)
21.5/16 (0.846/0.630) 21.5/16 (0.846/0.630)
1.1 1.1
Fuse, Thermal Protector for Fan Motor
Thermistor Thermistor
R410A R410A
EEV(in Outdoor unit or BD) EEV(in Outdoor unit or BD)
4×18(including earth) 4×18(including earth)
